| Print Technology |
Industrial piezoelectric inkjet |
| Ink Types |
Environmental protective UV ink |
| RIP Software |
PhotoPrint Taimes DX RIP |
| Colour Configuration |
4 Color / 6 Color / White / Varnish Option |
| Operating System |
Win7/10 64Bits |
| Image Format |
TIFF/JPEG/EPS/PDF/AI |
| Printhead Height |
0 ~ 90mm Above Media Adjustable |
| Media Type |
Wood panel, Aluminium panel, door plank, paperboard, PVC expansion sheet, Ceiling panel, glass, ceramics, acrylic, PVC, etc.,. |
| Maximum Printing Area |
Panel: 2,500mm(width) x 1,300mm (depth) |
| Maximum Weight of Material |
Panel: <=100 kg/m2 |
| UV Curing Lamp |
LED Water Cooling System |
| Data Interface |
Hi-Speed USB 2.0 |
| Temperature & Humidity |
15-32°C (59 to 90°F) 20°C (68°F) or more recommended 35 to 80% RH (No condensing) |
| Operating Noise |
<= 80dB |
| Maximum Power |
5KW |
| Access Parameter |
AC220V(± 5%), 50HZ/60HZ |
| Machine Dimension / Weight |
L4100x W2000 x H1350mm / Net Weight 1350KG |
| Package Dimension / Weight |
L4240 x W2,180 x H1550mm / Gross Weight 1530KG |
