Print Technology Industrial piezoelectric inkjet
Ink Types Environmental protective UV ink
RIP Software PhotoPrint Taimes DX RIP
Colour Configuration 4 Color / 6 Color / White / Varnish Option
Operating System Win7/10 64Bits
Printhead Height 0 ~ 90mm Above Media Adjustable
Media Type Wood panel, Aluminium panel, door plank, paperboard, PVC expansion sheet, Ceiling panel, glass, ceramics, acrylic, PVC, etc.,.
Maximum Printing Area Panel: 2,500mm(width) x 1,300mm (depth)
Maximum Weight of Material Panel: <=100 kg/m2
UV Curing Lamp LED Water Cooling System
Data Interface Hi-Speed USB 2.0
Temperature & Humidity 15-32°C (59 to 90°F) 20°C (68°F) or more recommended 35 to 80% RH (No condensing)
Operating Noise <= 80dB
Maximum Power 5KW
Access Parameter AC220V(± 5%), 50HZ/60HZ
Machine Dimension / Weight L4100x W2000 x H1350mm / Net Weight 1350KG
Package Dimension / Weight L4240 x W2,180 x H1550mm / Gross Weight 1530KG
